1

Equipment Model

LRS-6

2

Equipment Output

1~6 t/h

3

Main Frame

L×W×H=7900×2000×2200 mm

4

Hot Water Tank

Capacity: 4.0 m³<br>Overall Dimension: L×W×H=1800×2000×2000 mm

5

Emulsion Mixing Tank

Capacity: 3.8 m³<br>Overall Dimension: L×W×H=1600×2000×1800 mm

6

Asphalt Tank

Capacity: 4.5 m³<br>Overall Dimension: L×W×H=1900×2000×2000 mm

7

Finished Product Tank

Capacity: 1.5 m³<br>Overall Dimension: L×W×H=1600×1000×1000 mm

8

Asphalt Pump

Model: LCB-3A<br>Motor: Y160M-4-3KW<br>Flow Rate: 3 t/h

Thermal oil insulation type<br>Variable frequency speed regulation

9

Emulsion Pump

Model: LCB-3B<br>Motor: Y160M-4-3KW<br>Flow Rate: 3 t/h

Variable frequency speed regulation

10

Emulsifier

Model: RH-6<br>Motor: Y180M2-2-30KW<br>Flow Rate: 8 t/h

11

Finished Product Delivery Pump

Model: 3QGB60X2-46<br>Motor: -<br>Flow Rate: -

12

Control Cabinet

Overall Dimension: L×W×H=700×450×1500 mm
